All-rounder with maximum reach for safe and comfortable working
Efficient and safe work processes
Thanks to diverse safety and assistance systems, flexible profile settings, and modern machine technology, work processes are made safer, more productive, and more sustainable. They enable individually tailored workflows, faster decision-making, reduced downtime, and optimal process overview.
Limitless ways of application
Thanks to high stability when handling heavy loads both in extended and swing positions and a wide range of compatible attachments, Paus telescopic swing loaders are ideal partners in the communal sector, construction, landscaping, underground engineering and cable construction.
In addition to standard applications with buckets or pallet forks, this machine series demonstrates versatility in winter service, mulching, mowing, pruning, tree surgering and maintenance works. The usage of a working platform completes the multifunctionality of the equipment carrier and enables safe working at heights.
PRODUCT HIGHLIGHTS
Intuitive control
- The ergonomic joystick with clearly defined functions and an armrest ensure comfortable, fatigue-free control of the machine, even during extended work periods.
- The clearly arranged control panel with optimally arranged switches provides quick access to all functions and menu subgroups.
- The 7'' color display with optional touch function offers a clear overview of the machine data and enables simple control of all functions.
- This is complemented by Paus Controller, which ensures user-friendly operation of the display, even in difficult terrain by providing precise control.
Comfortable cabin
- The high-quality seat (optionally air-suspended) delivers superior comfort and promotes a comfortable sitting posture, even during extended work periods.
- The roof lattice window enhances visibility, increases daylight inside the cabin and improves driver safety.
- The steps on both sides provide safe and comfortable access to the cabin from all sides of the vehicle.
- The rear window heater rapidly removes frost and condensation, ensuring clear visibility in cold weather.
Safety
- The load moment monitoring system in longitudinal and transverse direction observes the machine's balance, protects against overload and enables safe operations even for inexperienced drivers.
- The ROPS/FOPS II cabin ensures optimal protection for the driver in the event of an accident or falling objects.
- Additional circuits are securely housed in the telescope tube to shield them from mechanical stress, wear and temperature fluctuations.
- The electronic limit position damping improves working comfort, reduces vibrations and shock loads, protects mechanical components and extends the machine's service life.
Intelligent technology
- Assistance systems can be adjusted to the driver's needs to enhance safety and comfort by adapting to working conditions and personal preferences.
- The machine behavior can be tailored to the respective application via user profiles: fast, medium, slow.
- The cruise control enables setting a constant speed, reducing driver fatigue.
- IntelliSpeed prevents engine overspeed, saves fuel, reduces noise levels and protects engine components.
TSL 9088 PRO
| Weight | 7,600 kg |
| Engine Deutz | TCD 3,6/85 kW |
| Bucket volume | 1,0 m³ |
| Dumping height | 4,080 mm |
| Stacking height | 4,830 mm |
| Tipping load max. | 4,610 kg |
TSL 9075 PRO
| Weight | 7,500 kg |
| Engine Deutz | TD 2,9/55.4 kW |
| Bucket volume | 1,0 m³ |
| Dumping height | 4,080 mm |
| Stacking height | 4,830 mm |
| Tipping load max. | 4,096 kg |
IntelliSpeed
Reduce engine RPM, increase efficiency!
Use the additional function at maximum speed. Discover the advantages of the TSL 9088 Pro:
✔ 20 % fuel savings with CO² reduction
✔ Reduced noise level for more comfort for the driver & environment
✔ Less wear and tear with a longer service life for machine components
✔ Regulated braking effect on accelerator pedal return
More information available on request!
Maximum versatility with a wide variety of attachments
The applications of the Telescopic Swing Loader Pro Series can be further expanded with a wide range of attachments. From classic material handling to specialized applications, the machine can be flexibly adapted to new tasks.
The proven quick-change system ensures that attachments can be changed swiftly and safely. This ensures the swing loader remains a powerful and cost-effective tool, even as site requirements change.
Powerful engines with up to 85 kW and additional hydraulic control circuits with a capacity of up to 140 l/min enable the drive of high-performance attachments.
A selection of attachments is presented here. Further equipment options are available.
A selection of attachments is presented here. Other options are possible.
